The VIEW Precis 200 from QVI® is a high accuracy micro-metrology system for wafers, masks, MEMs, and HDD heads. The Precis combines precision stages, proven microscope optics, and a choice of three world-class metrology software packages to provide new levels of capability for process metrology. The VIEW Precis delivers sub- micron field-of-view and point-to-point measurement accuracy on features as small as 0.65 μm. Dual Loop Servo Motion Control for precise and stable part translation Ergonomic control station and compact footprint Exclusive Mirco Focus Block provides rigid, repeatable focus motion.

 Metrology Software:

    VIEW Metrology Software (VMS)

    Optional: Elements® metrology software

    Optional: Measure-X® metrology software

Available Optional Software Modules:

   • Area Multi-Focus

   • SmartProfile 3D GD&T MeasureFit® Plus

   • Advanced image filtering, image stitching custom UI

   • VMS Off-Line Workstation Software

   •  Digital IO

Featuring:

applications for Precis include：

     Semiconductor/Electronics

               PCBs and Stencils

                Photo masks

                Lead frames, wire bonds, flex circuits, connectors

                SMT component placement

                Solder paste/Epoxy glue dot

                Chip carriers and trays

                Inkjet printer cartridges

     Data Storage

                Suspensions

                Slider and Head Gimble Assemblies (HGA)

                Disk Media substrates

   Precision plastic molded and machined parts
               Dies and tooling
               Medical devices
               Fuel injection components
               Watch components
